AISI 304 Hex Metal Mesh Refractory Lining Flex Metal 1.8X20X50mm

1.8X20X50mm AISI 304 Hex Metal Refractory Lining & Flex Metal
Descriptions :
XINGKUAN TECH is defined as a unique hexagonal cellular mesh steel, made of flat bar which is designed to provide brilliant retention and reinforcement of thin wall refractories and fully complements dense hydraulic and chemically bonded refractories in resisting erosion. It acts as a surface framework to hold cement or refractory in position, and relieves stress in the lining’s upper crust, retarding erosion, corrosion, blistering and cracking.

The flexibility of XKTSteel’s Hex Metal allows it to be rolled, and easily conforms to circular shapes. It is recommended for use when placement is spaced from the steel shell to allow room for thick insulation between the metal shell and the armoured surface

Bonding type : Instead of lance tabs, holes are punched through the walls of the hexmetal cell. Refractory can then flow through these holes to achieve a bond from one cell to another.

Lance type :this style has lance tabs protruding from the walls of the hexagonal cell to act as anchorage for the refractory.

Applicaions :

• As refractories, hex steel mesh has Flexibility, high strength and erosion resistant characteristics. Hex steel mesh is an excellent choice of refractory linings in furnaces, reactors, cyclones, ducts and flues. It is mainly used in power plant, cement plant, Steel, petroleum, chemical industry, power generation and other large devices. The hex metal can largely improve the heat erosion and abrasion resistance.
• Hex mesh used for floors, hex mesh provides long term protection for armor applications in industrial floors. Specifically: Loading docks, ramps, high traffic aisles for forklifts and trucks, hot floors for foundry, forge and steel mills, refuse disposal plant floors and almost anywhere floors are subject to severe impact and rolling loads will benefit with Hex mesh.
• Since Hex Metal's flexibility allows it to be rolled, it easily conforms to circular shapes. It is ideal for lining Ducts, Furnaces, Reactor Vessels, Cyclones, Flue Gas Lines and other high temperature equipment of virtually any shape or configuration. Hex metal and flex metal refractory linings are both flexible, mesh grating used in reinforcing linings, floors and any cement structures needing added support.


Features :

• High wear resistance high temperature corrosion resistance.
• Strong Thermal state impact ability.
• Good mechanical processing performance.
• Used in about 1300 °C.
• High weldability long lifetime easy to install.

Notice :

1. Small sample in stock is free
2. Packing : pallet or as per request
3. Pls send us : thickness , hole type , hole size , deepth , length , width , quantity and other special request
4. If drawings you are at hand , it will be more helpful to communicate for your real request .
5. Professional team do professional work together .
6. We will give you suggestion after commnunication .
